Product Description
The Amran CT255-122 Current Transformer (CT) is designed for accurate current measurement and monitoring in industrial, commercial, and utility systems.
This CT features a 1200:5A ratio, 600V insulation level, and a 10kV full-wave BIL rating for safe operation under demanding conditions. Built to operate across a 50–400Hz frequency range, it offers excellent versatility in power systems.
The durable plastic case provides protection and reliability, while its panel-mount design allows easy installation in switchgear, panels, and distribution systems.
Key Features:
-
Brand: Amran
-
Model: CT255-122
-
Current Ratio: 1200:5A
-
Insulation Level: 600V
-
BIL Rating: 10kV (Full Wave)
-
Frequency Range: 50–400Hz
-
Case: Plastic Cased
-
Mounting: Indoor / Panel Mount
-
Applications: Metering, Protection, Industrial & Utility Electrical Systems
