Product Description
The Burndy K2A25U is a dual-rated aluminum universal terminal lug designed to securely connect two copper or aluminum conductors. Similar in design to the K2A36U but sized for smaller conductors, this mechanical lug delivers dependable performance in power distribution, switchgear, and industrial electrical applications.
Features & Specifications:
-
Conductor Range:
-
Aluminum (AL): 6 AWG to 350 kcmil stranded
-
Copper (CU): 4 AWG to 250 kcmil stranded
-
-
Number of Conductors: Accommodates two (2) conductors
-
Material: High-strength aluminum alloy with electro-tin plating for corrosion resistance
-
Connection Type: Mechanical (solderless) with two slotted set screws
-
Mounting: Single mounting hole designed for a 1/2-inch stud
-
Voltage Rating: Rated up to 600 V (also rated up to 35 kV)
-
Installation Torque: Recommended installation torque of 275 in-lbs
Applications:
Ideal for power distribution, panelboards, switchgear, and industrial electrical systems requiring reliable dual-conductor terminations for copper and aluminum wire.
