Product Description
The Burndy YA32A3 is a dual-rated, two-hole aluminum compression lug from the HYLUG™ series, designed for reliable termination of both 400 kcmil aluminum and stranded copper conductors. Ideal for industrial and power distribution applications, it provides a secure, corrosion-resistant connection for equipment pads and terminals.
Key Features & Specifications:
-
Conductor Size: 400 kcmil (Aluminum and Stranded Copper)
-
Material: High-conductivity wrought aluminum, electro-tin plated to resist corrosion
-
Voltage Rating: 600 volts up to 35 kV
-
Number of Holes: Two-hole configuration for secure attachment and anti-rotation
-
Stud Size: 1/2 inch
-
Stud Hole Spacing: 1.75 inches between holes
-
Barrel Type: Standard (straight) barrel, pre-filled with PENETROX™ A13 oxide inhibitor
-
Die Index: Green color code, Die Index 472 for compatible crimping tools
-
Overall Length: 6.15 inches
-
Application: Industrial electrical and power distribution terminations
