Product Description
The Burndy YA392N Compression Lug is a premium-grade copper compression connector engineered for secure and reliable electrical terminations on large conductors. Rated for 750 kcmil copper, this lug features a 2-hole mounting design with 1/2″ stud size and extended long barrel construction, allowing for multiple crimps and a robust mechanical connection. The tin-plated finish enhances corrosion resistance, making it ideal for power distribution, grounding, and bonding applications in industrial, commercial, and utility electrical systems.
Product Details
-
Brand: Burndy (HYLUG™)
-
Model / Part Number: YA392N
-
Type: Copper Compression Lug / Cable Connector
-
Conductor Size: 750 kcmil copper stranded
-
Number of Holes: 2-Hole design prevents rotation
-
Stud Size: 1/2″
-
Stud Hole Spacing: 1-3/4″ center-to-center
-
Barrel Style: Long barrel with chamfered wire entry
-
Finish: Tin-plated copper for corrosion resistance
-
Voltage Rating: Suitable for up to very high (typically AC 600 V to 35 kV range)
-
Temperature Rating: 90 °C
-
Condition: New
-
Application: Power distribution, grounding, bus bar terminations, industrial wiring
Key Features
-
Designed for 750 kcmil conductor terminations
-
Copper construction with tin plating for excellent conductivity and corrosion resistance
-
2-hole configuration ensures secure mounting on studs
-
Long barrel design allows multiple crimps for a strong, reliable connection
-
Chamfered barrel entry helps prevent strand damage during insertion
-
Ideal for industrial, commercial, and utility electrical systems
-
Compatible with standard compression tools and dies
IS.05222025.05
