Product Description
The Edison JDL50 is a 50 Amp, 600 Volt AC Class J time‑delay fuse designed to deliver reliable overload and short‑circuit protection for industrial and commercial electrical systems. With a dual‑element, current‑limiting, time‑delay design, the JDL50 tolerates harmless motor or transformer inrush currents and transient surges yet reacts fast under sustained overloads or fault conditions — making it a versatile choice for motors, transformers, panelboards, feeders, and general‑purpose circuits.
Product Details
-
Brand: Edison (by Eaton)
- Condition: Used
-
Model / Part Number: JDL50
-
Fuse Class: Class J, Dual‑Element Time‑Delay
-
Amperage Rating: 50 A
-
Voltage Rating: 600 V AC
-
Interrupt Rating: 200 kA (RMS Symmetrical) at 600 V AC, self‑certified up to 300 kA under certain conditions.
-
Body Style / Size: Cylindrical cartridge (approx. 1.06″ diameter × 2.38″ length) with ferrule‑end terminals.
-
Fuse Type: Time‑Delay / Current‑Limiting / Dual‑Element
-
Approvals / Standards: UL Listed, CSA Certified, CE Marked, RoHS Compliant.
Key Features
-
Dual‑element time-delay design withstands momentary surges (e.g. motor start‑up) without nuisance fuse blowouts.
-
Current‑limiting construction sharply reduces fault let‑through energy — protecting downstream components and reducing damage risk from short circuits.
-
High 200 kA interrupt rating (600 V AC) — robust protection for industrial circuits and high-fault environments.
-
Compact Class J cartridge format — ideal for space‑limited panels, compact switchgear, or retrofits.
-
Versatile application: motors, feeders, transformers, panelboards, control circuits — wherever dependable overcurrent protection is required.
-
