Product Description
The Ferraz Shawmut A70P125-4 is a fast-acting Amptrap semiconductor fuse designed to protect sensitive power semiconductor devices such as diodes, thyristors, and SCRs.
Rated at 125 amps and 700 volts AC/DC, this fuse provides excellent short-circuit protection, quickly interrupting high fault currents up to 100kA.
Built for high-power electronics, drives, inverters, and UPS systems, the A70P125-4 ensures reliable performance, superior current limitation, and enhanced equipment protection in demanding industrial environments.
Product Details:
-
Brand: Ferraz Shawmut (Mersen)
-
Model / Part Number: A70P125-4
-
Condition: Used
-
Type: High-Speed Semiconductor Fuse
-
Fuse Series: Amptrap A70P
-
Current Rating: 125A
-
Voltage Rating: 700V AC/DC
-
Interrupting Rating: 100kA RMS Symmetrical
-
Mounting Type: Bolt-on
-
Body Style: Cylindrical
-
Fuse Class: Semiconductor
-
Standards: UL Recognized, CSA Certified, RoHS Compliant
-
Applications:
-
Semiconductor device protection
-
Variable speed drives
-
UPS and inverter systems
-
Power converters and rectifiers
-
DC power distribution
-
Key Features:
-
Fast-acting semiconductor protection minimizes damage to sensitive components.
-
High interrupting capacity up to 100kA for superior safety.
-
Low I²t values reduce let-through energy.
-
Rugged Amptrap construction ensures reliability under high-stress conditions.
-
Compact bolt-on design for easy installation and maintenance.
