Product Description
The Ferraz Shawmut R200755CF00 Amp-Trap Fuse is a 250-amp, 250-volt, 200kA-rated power fuse designed for industrial and high-performance electrical protection. This fuse ensures superior short-circuit and overload protection for power distribution systems, semiconductor applications, and high-energy circuits.
Built to Amp-Trap standards, the R200755CF00 features fast-acting, current-limiting performance to minimize damage to equipment during fault conditions. The included D310020 microswitch provides additional monitoring capability, allowing real-time fuse status detection for enhanced system safety and control.
Ideal for use in inverters, UPS systems, drives, rectifiers, and power conversion equipment, this fuse offers high interrupting capacity, low I²t energy let-through, and UL/IEC compliance for reliable global operation.
Product Details
-
Brand: Ferraz Shawmut (Mersen)
-
Series: Amp-Trap
-
Manufacturer Part Number: R200755CF00
-
Amperage Rating: 250 A
-
Voltage Rating: 250 V AC/DC
-
Interrupting Rating: 200 kA
-
Fuse Type: Fast-Acting / Current-Limiting
-
Fuse Class: Amp-Trap
-
Includes: D310020 Fuse Microswitch
-
Mounting Style: Bolt-on / Holder Compatible
-
Body Style: Square Body
-
Standards: UL Recognized, IEC Certified
-
Condition: Used
Key Features
-
250A, 250V high-performance power fuse for industrial applications
-
200kA interrupting capacity ensures superior short-circuit protection
-
Fast-acting Amp-Trap design minimizes equipment stress
-
Includes D310020 microswitch for fuse status monitoring
-
Suitable for UPS, inverter, and power conversion systems
-
UL and IEC compliant for global use
-
Compact, durable construction for reliable performance
-
Low I²t energy let-through for equipment longevity
