Product Description
The General Electric DXLCA41 is a heavy-duty single-barrel mechanical lug designed for dependable electrical conductor termination in industrial and commercial power systems. Manufactured from high-strength aluminum, this lug provides a secure mechanical connection for a wide range of conductor sizes and is dual-rated for both copper and aluminum conductors. Its straightforward design allows for easy installation in switchgear, panels, and distribution equipment where reliability and long service life are critical.
Key Features
Single-barrel mechanical lug for power distribution applications
Dual-rated for copper and aluminum (CU/AL) conductors
High-strength aluminum construction for durability
Mechanical screw-type termination for secure connections
Suitable for industrial and commercial electrical systems
Technical Specifications
Manufacturer: General Electric
Model / Part Number: DXLCA41
Conductor Range: 2 AWG to 600 kcmil (MCM)
Material: High-strength aluminum
Design: Single barrel, one conductor
Mounting Holes: One hole (available in 1/4 in, 1/2 in, or 9/16 in versions)
Connection Type: Mechanical screw terminal
Conductor Rating: Copper and Aluminum (CU-AL)
Applications
Electrical panels and switchgear
Power distribution equipment
Industrial and commercial electrical installations
Feeder and branch circuit terminations
