Product Description
The Square D D2965 is a heavy-duty mechanical terminal lug designed for secure electrical connections in industrial and commercial power systems. This single-barrel lug is specifically engineered to handle high-amperage loads, accommodating large wire sizes from 3/0 AWG up to 600 kcmil (MCM). Its "AL7CU" rating ensures it is fully certified for use with both aluminum and copper conductors, providing essential versatility for various power distribution and circuit breaker applications.
Item Specifics
-
Brand: Square D/Schneider Electric
-
MPN: D2965
-
Material: Tin-Plated Aluminum Alloy
-
Conductor Type: Aluminum or Stranded Copper (AL7CU)
-
Wire Range: 600 kcmil (MCM) - 3/0 AWG
-
Number of Ports: 1 (Single Barrel)
-
Mounting Type: 1-Hole Bolt-On
-
Compatibility: Used with Square D Molded Case Circuit Breakers and Power Distribution Blocks
Key Features
✔ Dual Rated (AL7CU): Certified for use with both copper and aluminum stranded wiring.
✔ Tin-Plated Finish: Provides excellent conductivity and superior corrosion resistance in industrial environments.
✔ High Capacity: Engineered to handle high-current applications up to 600 MCM.
✔ Compact Footprint: Designed to fit within the narrow terminal spacing requirements of industrial breakers.
✔ Robust Hardware: Features a heavy-duty set screw for maximum clamping pressure and vibration resistance.
Technical Specifications
-
Voltage Rating: 600V Max
-
Temperature Rating: 75°C / 90°C Dual Rated
-
Wire Range (Min): 3/0 AWG
-
Wire Range (Max): 600 kcmil (MCM)
-
Material Construction: Extruded Aluminum Alloy
-
Connection Type: Mechanical (Set Screw)
