Product Description
The Thern 465 is a compact worm‑gear hand winch built for horizontal pulling applications, not rated for lifting. It offers 750 lb line‑pull capacity, making it ideal for light‑duty pulling, tensioning, or relocation tasks in industrial, marine, or general‑purpose settings.
Key Specifications
-
Load Rating: 750 lb (pulling only)
-
Gear Type: Worm Gear, open‑gear design
-
Recommended Use: Horizontal pulling — not for lifting or overhead use
-
Drum Capacity (wire rope): up to ~ 130 ft (with 1/8" or 3/16" rope) depending on rope diameter and drum loading
-
Compact and portable, with a manual handle and no brake included (open‑gear configuration)
Recommended Applications
-
Pulling cable, rope, or wire lines horizontally
-
Winching equipment or material along flat surfaces
-
Industrial, marine, or maintenance tasks that require controlled pulling force
-
Projects where controlled, manual pulling is needed — not for overhead lifting or load‑bearing lifts under vertical load
***Important Safety Note***
This model is not rated for lifting — it is strictly for pulling or horizontal movement. Do not use it to hoist or suspend loads, or transport loads over people.
